Custom connectors

A custom connector (called a component in Prismatic) is a self-contained package of actions, triggers, data sources, and connections that you publish to Prismatic and use inside low-code integrations or code-native integrations. Connectors are written in TypeScript using the Spectral SDK (@prismatic-io/spectral). Each connector is defined by calling component(), which accepts a ComponentDefinition object.

ComponentDefinition shape

The full type from ComponentDefinition.ts:

type ComponentDefinition<TPublic extends boolean, TKey extends string> = {
  /** Unique programmatic key for this component. */
  key: TKey;
  /** Whether this component is available to all orgs (only Prismatic-managed public components use true). */
  public?: TPublic;
  /** How this component appears in the Prismatic UI. */
  display: ComponentDisplayDefinition<TPublic>;
  /** Named actions this component exposes. */
  actions?: Record<string, ActionDefinition<any, any, boolean, any>>;
  /** Named triggers this component exposes. */
  triggers?: Record<string, TriggerDefinition<any, any, boolean, any> | PollingTriggerDefinition<any, any, any, any, any, any>>;
  /** Named data sources this component exposes. */
  dataSources?: Record<string, DataSourceDefinition<any, any, any>>;
  /** Connection definitions used by this component's actions. */
  connections?: ConnectionDefinition[];
  /** Optional global hooks (e.g., a component-wide error handler). */
  hooks?: ComponentHooks;
  /** Documentation URL. Required for public Prismatic components; optional for custom. */
  documentationUrl?: string;
};

The display field uses ComponentDisplayDefinition:

type ComponentDisplayDefinition<TPublic extends boolean> = {
  label: string;      // Human-readable name shown in the UI
  description: string; // Short description of what this connector does
  iconPath: string;   // Path to icon file relative to built source
  category?: string;  // Optional grouping category
};

Minimal complete example

The following example shows a complete connector with one action:

import {
  component,
  action,
  input,
  connection,
} from "@prismatic-io/spectral";

const myConnection = connection({
  key: "myConnection",
  display: {
    label: "My API Connection",
    description: "Authenticate with My API using an API key",
  },
  inputs: {
    apiKey: {
      label: "API Key",
      type: "password",
      required: true,
      comments: "Your My API secret key",
    },
  },
});

const listItems = action({
  display: {
    label: "List Items",
    description: "Retrieve all items from My API",
  },
  inputs: {
    connection: input({
      label: "Connection",
      type: "connection",
      required: true,
    }),
    pageSize: input({
      label: "Page Size",
      type: "string",
      default: "50",
      comments: "Number of items to return per page",
    }),
  },
  perform: async (context, params) => {
    const apiKey = params.connection.fields.apiKey as string;
    const response = await fetch(
      `https://api.example.com/items?limit=${params.pageSize}`,
      { headers: { Authorization: `Bearer ${apiKey}` } }
    );
    const data = await response.json();
    return { data };
  },
});

export default component({
  key: "myComponent",
  display: {
    label: "My Component",
    description: "Connect to My API",
    iconPath: "icon.png",
  },
  actions: { listItems },
  connections: [myConnection],
});

Component structure

A typical connector project has this layout:

my-component/
├── src/
│   ├── index.ts        # component() call — the entry point
│   ├── actions.ts      # action() definitions
│   ├── triggers.ts     # trigger() definitions
│   ├── dataSources.ts  # dataSource() definitions
│   ├── connections.ts  # connection() definitions
│   └── inputs.ts       # shared input() definitions
├── assets/
│   └── icon.png
├── package.json
└── tsconfig.json

All keys (key on component, action, connection, etc.) must be unique within their scope and should use camelCase. They are programmatic identifiers used in the Prismatic API and cannot be changed after publishing.

Building and publishing

Install dependencies

npm install @prismatic-io/spectral

Build the component

npm run build

Publish to Prismatic

prism components:publish

Explore the building blocks

Actions

Define the operations your connector performs — API calls, data transformations, and more.

Triggers

Define how an integration flow is started, including webhook and polling triggers.

Data sources

Populate config wizard dropdowns and forms by fetching data from external APIs.

Connections

Define authentication schemes: API keys, username/password, and OAuth 2.0.

Inputs

Declare typed input fields that are configured by integration builders.

Branching

Route execution down different paths based on action results.

Error handling

Use global hooks and typed errors to handle failures gracefully.
